Technical Parameters
| MODEL | 6SXZ-640A |
| Chutes/Channels | 10/ 640 |
| Throughput(T/H) | 15-30 |
| Accuracy(Percent) | ≥99.99% |
| Power(Kwh) | 6.0 |
| Power Voltage | 220V/50Hz |
| Air compressure(Mpa) | 0.6-0.8 |
| Air Consumption | ≤3.9 |
| Weight(Kg) | 1820 |
| Dimension(L*W*H) | 3895*1621*1816mm |
Product Features
► IOT color sorter system
Highly humanized interface of human-machine interaction, Smart
cloud interconnect,Remote control, accurate big data statistics and
analysis.Call the multiple preset color selection modes at any
time.
► HD image capture system
Full-color high-speed CCD sensor recognizes 0.04mm²area,Nikon
camera,super high resolution,ultra-sensitive ,wide vision, low
distortion.
► Multi-core parallel image processing system
Multi-core parallel image processing system, flexible matching and
synchronous operation of color sorting/shape sorting.
► Intelligent high-frequency solenoid valve
Ultra-low air consumption, ultra-low carryover ratio, intelligent
detect the working status of ejectors,avoid the fault and prolong
the life of ejectors.
► Shadowless colorful spectrum LED
Taiwan Yiguang,shadow-less LED colorful light source, multi-angle
shadow-less light path technology.
► Input and Output system
Adopting a new pressure-resistant structure to feed, which greatly
increases the output of the machine and ensures the stability of
the machine.The straight-through discharge structure solves the
problem of material blocking and stacking.
Application Fields
This series model can sort different kinds of
cereals,grains,beans,such as
corn,wheat,oat,buckwheat,sesame,mung,peanut and so on
JIETAI Color Sorter'Advantages
A.Running Stable
Quality assurance,
long service life.
Non-invasive sorting for all-round protection of easy to damage and
break materials.
B.Minimalist User Interface
Let you far away from debugging difficult and operation complex
trouble.
C.Super Brain Identification
Intelligent sorting,accurate identification of extremely small
color difference and extremely small heterochromatic area
materials.
D.Intelligent Valve
Intelligent control of blowing frequency,It can be achieved
optimized carryover and ultra-low air consumption.
Intelligent detection of valve running status which makes the
failure and operation life of the valve under control.
E.Powerful Function
Shape selection and color selection,intelligent color sorting plans
for flexible matching.
F.After-sale Without Worry
provide free training,consulting and technical support for users;
Provide free warranty service for one year(except the wearing spare
parts)
Materials Sorting Performance
Our Workshop&Warehouse
Cooperation Case
At present, our products have been distributed to more than 50
countries and regions around the world, providing high-quality
products and services to global customers.
Our Service
Our Service Team
Before sales services
We will help you know ahout our color sorter,meets your special
requirementaccording to actual condition.
After sales services
① Provide free training,consulting and technical support for users;
② Provide personalized programs to the demands of customers;
③ Upgrade software for free for a life time;
④ Provide free warranty service for one year(except the wearing spare
parts);
⑤ Provide 7*24 hours consultation and urgent servicce for users.
Plaese feel free to inquire if you are interested in our procducts!
